The thermal oil boiler allows you to achieve high temperatures (350 ℃ ) at low pressure and there is no danger of explosion by high pressure.
The thermal oil circulates in a closed cycle with less thermal loss and no necessity for water supply or drainage.
The thermal oil is indirectly heated by liquid and forced to circulate in the system. It can maintain the homogenous temperature distribution without local degradation of temperature.
It can be easily applied to any area where thermal oil can be circulated.
If necessary, you can easily adjust the thermal capacity and temperature.
Model
B&B-T
20
30
40
50
60
80
100
120
150
180
200
250
300
350
400
Rated
evaporation
103kcal/hr
200
300
400
500
600
800
1000
1200
1500
1800
2000
2500
3000
3500
4000
Max pressure
kg/㎠
10
Max temperature.
℃
350
Fuel
consumption
kg/hr
23.3
35.0
46.7
58.4
70.0
97.7
122.1
146.5
183.2
219.8
244.2
305.3
366.3
427.4
488.4
Specifications
pipe
A
50
65
65
80
80
100
100
1215
125
150
150
150
200
200
200
operation weight
kg
2000
2800
3500
4300
4900
6400
7000
8000
9800
12000
15000
16000
20000
25000
30000
Installa-
tion exterior
Width
mm
1030
1180
1200
1320
1330
1500
1620
1750
1890
1970
2030
2160
2400
2700
2900
Depth
mm
1600
1750
2060
2250
2390
2900
3310
3500
3850
4210
4330
4950
5700
5800
6000
Height
mm
900
920
950
950
950
950
1000
1100
1190
1300
1325
1500
1520
1750
1850
Circulation pump
r
Amount of circulation
㎥/hr
18
26
34
42
45
60
75
90
115
140
150
190
230
265
305
Depth
M
35
40
42
42
50
50
50
50
55
56
60
60
65
65
70
Motor
HP
5
7.5
7.5
7.5
10
15
15
20
25
30
40
50
60
75
100
Chimney
mm
230
230
270
320
350
430
450
500
550
620
670
720
850
950
1000
1. These specifications are subject to change depending on the customer's request and for the purpose of quality improvement.
